Enhance Performance with Parker F12 Series Motor
Experience the superior performance of Parker F12 Series Motor that has been designed for high efficiency and reliability in demanding applications. This solid motor includes advanced design features that guarantee excellent energy output, easy operation, and long life span. The F12 Series enjoys unequalled sturdiness and precision, which makes it suitable for heavy duty machinery. Get a consistent hydraulic system with Parker’s F12 Series Motor meant for regular reliable performance. Study all technical peculiarities and benefits to find out why industrial hydraulic systems are using Parker.
- Customized Solutions
- High Efficiency
- Reasonable Pricing
- Technical Support and Service
The Parker F12 Series Motor offers high efficiency, robust design, and exceptional durability for demanding industrial applications.
-
Description of Parker F12 Series Motor: Information and Specifications
The F12 series supports intermittent operating speeds up to 7,300 RPM and continuous speeds up to 6,700 RPM, with displacement options ranging from 30.0 cm³/rev to 125.0 cm³/rev. The series conforms to ISO and SAE mounting flange and shaft end configurations, and is available in a compact cartridge version for space-saving installations.
Key Features of the F12 Series Motor
- Unique spherical piston design for high shaft speeds and operating pressures
- Heavy-duty roller bearings for handling substantial external axial and radial loads
- Laminated piston rings for enhanced sealing and thermal shock resistance
- Compact design with a 40° angle between the shaft and cylinder barrel
- High overall efficiency, reducing fuel or electric power consumption
The Parker F12 series features a compact design with unique pistons, robust bearings, and high efficiency, ensuring high speed, pressure, and reduced power consumption.
Parker F12 Series Motor Specifications
| Frame Size | Displacement (cm³/rev) | Max Intermittent Pressure (bar) | Max Continuous Pressure (bar) | Max Intermittent Speed (rpm) | Max Continuous Speed (rpm) | Min Continuous Speed (rpm) | Max Intermittent Flow (l/min) | Max Continuous Flow (l/min) | Main Circuit Temp Max (°C) | Main Circuit Temp Min (°C) | Mass Moment of Inertia (kg m²) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| F12-30 | 30.0 | 480 | 420 | 7300 | 6700 | 50 | 219 | 201 | 80 | -40 | 1.7 | 12.0 |
| F12-40 | 40.0 | 480 | 420 | 6700 | 6100 | 50 | 268 | 244 | 80 | -40 | 2.9 | 16.5 |
| F12-60 | 59.8 | 480 | 420 | 5800 | 5300 | 50 | 347 | 317 | 80 | -40 | 5.0 | 21.0 |
| F12-80 | 80.4 | 480 | 420 | 5300 | 4800 | 50 | 426 | 386 | 80 | -40 | 8.4 | 26.0 |
| F12-90 | 93.0 | 420 | 350 | 5000 | 4600 | 50 | 465 | 428 | 80 | -40 | 8.4 | 26.0 |
| F12-110 | 110.1 | 480 | 420 | 4800 | 4400 | 50 | 528 | 484 | 80 | -40 | 11.2 | 36.0 |
| F12-125 | 125.0 | 480 | 420 | 4600 | 4200 | 50 | 575 | 525 | 80 | -40 | 11.2 | 36.0 |
Parker F12 Series Motor Advantages and Applications
Direction and Position
- Direction: Determine the motor/pump rotation direction (clockwise or counterclockwise) based on the specific application.
- Mounting Position: Ensure a stable mounting position that is easy to maintain, avoiding vibrations and shocks.
Connections
- Interfaces: Ensure all hydraulic lines and connections are clean and free of debris.
- Fasteners: Use the correct torque to secure all bolts and nuts, avoiding over-tightening or under-tightening.
Hydraulic System
- Hydraulic Oil: Use the manufacturer-recommended hydraulic oil and ensure it is clean and of appropriate viscosity.
- Air Bleeding: Ensure all air is purged from the system before startup.
Pre-Start Checks
- Leak Check: Inspect all joints and seals for any signs of leakage.
- Pressure and Flow: Ensure the system pressure and flow are within the specified range.
Startup and Operation
- Initial Startup: During the initial startup, operate at low speed and gradually increase to normal operating speed.
- Monitoring: Regularly monitor the motor/pump’s operating conditions, including temperature, noise, and vibration.
Maintenance
- Regular Inspections: Regularly inspect and replace hydraulic oil and filters to keep the system clean.
- Lubrication: Periodically lubricate all moving parts as per the manufacturer’s recommendations.
Parker F12 Series Motor Catalog
| F12-030-MF-IV-K-000-000-0 | Parker Motor Price | Contact Us |
|---|---|---|
| F12-030-MS-SV-T-000-000-0 | USD1285 | Inquiry about this Parts |
| F12-040-MS-SV-S-000-000-0 | USD1956 | Inquiry about this Parts |
| F12-040-MF-IV-K | USD2628 | Inquiry about this Parts |
| F12-060-MF-IV-D-000-000-0 | USD3299 | Inquiry about this Parts |
| F12-060-RS-SV-T-000-000-0 | USD3971 | Inquiry about this Parts |
| F12-080-RS-SV-T-000-000-0 | USD4642 | Inquiry about this Parts |
| F12-080-MF-IV-D-000-000-0 | USD5314 | Inquiry about this Parts |
| F12-090-MF-IV-D-000 | USD5985 | Inquiry about this Parts |
| F12-090-MS-SV-S-000 | USD6657 | Inquiry about this Parts |
| F12-110-MF-IV-D-000 | USD7328 | Inquiry about this Parts |
| F12-110-MS-SH-T-000-000-0 | USD8000 | Inquiry about this Parts |
Get In Touch
If you’re interested in exploring a range of F12 Moto, and you’re looking for a brand that matches the quality and reliability of industry leaders, consider LOYAL.
Interested in learning more about our products and how they can benefit your operations? Visiting our official website or reaching out to our customer service team through official channels will provide you with all the information and assistance you need.
Choose LOYAL for reliable, efficient, and innovative hydraulic solutions tailored to meet and exceed your expectations.
Latest Articles ※
Related Topics About Hydraulic Pump
Parker F12 Series Motor : Answers to Common Queries
Explore the advantages of the Parker F12 Series Motor for enhanced performance.
Q:How does the bent-axis design benefit the Parker F12 motor?
A:The bent-axis design of the parker f12 motor enhances its overall performance by providing higher efficiency and reliability. This design minimizes friction and wear, allowing for smoother operation under high pressure and speed. The bent-axis configuration also contributes to the motor’s ability to handle thermal shock resistance and high load capacities, making it suitable for demanding environments.
Q: In what applications is the Parker F12 typically used?
A: The parker f12 motor is used in numerous applications due to its robust and reliable performance. Common applications include industrial hydraulics, mobile machinery, and marine equipment. The motor’s ability to operate efficiently in open and closed loop circuits makes it versatile and adaptable for various operational needs.
Q:How can I get detailed technical information about the Parker F12?
A:For detailed technical information on f12, it is best to contact your local parker dealer for support. These dealers can provide specifications, performance data, and installation guidelines to help you maximize the motor’s capabilities.
